PE extruder and printing machine
|
Model |
CX-50-700 |
CX-55-900 |
CX-60-1100 |
|
Suitable matetial |
PO/PE/PLA+PBAT |
PO/PE/PLA+PBAT |
PO/PE/PLA+PBAT |
|
Film width(mm) |
100-600 |
300-800 |
500-1000 |
|
Film thickness(mm) |
0.01-0.10 |
0.01-0.10 |
0.01-0.10 |
|
Output(kg/h) |
45-80 |
60-100 |
70-120 |
|
Extrusion unit |
|
|
|
|
Screw diameter |
Φ50 |
Φ55 |
Φ60 |
|
Screw L/D |
28|30:1 |
28|30:1 |
28|30:1 |
|
Screw material |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
|
Barrel material |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
|
Main motor (kw) |
15kw |
18.5kw |
22kw |
|
Average power consume |
15kw |
25kw |
30kw |
|
Die unit |
|
|
|
|
Die head |
Φ60/100/120mm |
Φ80/120/150mm |
Φ100/200/220mm |
|
Take-up unit |
|
|
|
|
Roller width(mm) |
700 |
900 |
1100 |
|
Effictive width(mm) |
600 |
800 |
1000 |
|
Take-up speed |
10-110m/min |
10-110m/min |
10-110m/min |
|
Printing unit |
|
|
|
|
Max. Printing width(mm) |
595 |
795 |
995 |
|
Printing length(mm) |
250-700 |
250-700 |
250-700 |
|
Precision of color printing(mm) |
±0.2 |
±0.2 |
±0.2 |
|
Winding unit |
|
|
|
|
Winding type |
Central winding (roll change without stopping) |
Central winding (roll change without stopping) |
Central winding (roll change without stopping) |
|
Winding speed |
10-110m/min |
10-110m/min |
10-110m/min |
|
Voltage |
380V,50HZ,3PHASE |
380V,50HZ,3PHASE |
380V,50HZ,3PHASE |
|
Machine weight(T) |
4.5T |
5T |
5.5T |
|
Machine size(m) |
9*3.5*5.2m |
9*3.8*5.2m |
9*4*5.9m |
