ABA film blowing machine
|
Model |
CX-ABA-700 |
CX-ABA-900 |
CX-ABA-1100 |
|
Suitable materials |
HDPE,LDPE,LLDPE |
HDPE,LDPE,LLDPE |
HDPE,LDPE,LLDPE |
|
Film width |
200-600mm |
400-800mm |
400-1000mm |
|
Film thickness |
0.005-0.10mm |
0.005-0.10mm |
0.005-0.10mm |
|
Output |
75kg/h |
95kg/h |
120kg/h |
|
Extrusion unit |
85kg/h | 105kg/h | 130kg/h |
|
Screw diameter |
Φ45*2 |
Φ50*2 |
Φ55*2 |
|
Screw L/D |
30:1/32:1 |
30:1/32:1 |
30:1/32:1 |
|
Screw material |
Double alloy material
|
Double alloy material |
Double alloy material |
|
Barrel material |
Double alloy material |
Double alloy material |
Double alloy material |
|
Barrel cooling fan |
550w*6 |
550w*6 |
550w*9 |
|
Main motor |
11kw*2 |
15kw*2 |
18.5kw*2 |
|
Barrel temperature control |
3*3 |
3*3 |
3*3 |
|
Average power consume |
28kw |
35kw |
45kw |
|
Die unit |
60/80mm | 80mm | 100mm |
|
Die head |
120mm |
150mm |
250mm |
|
Temperature control |
12 |
12 |
12 |
|
Air ring |
Double tuyere wind ring |
Double tuyere wind ring |
Double tuyere wind ring |
|
Air blower |
2.1kw |
3kw |
4kw |
|
Take-up unit |
|||
|
Roller width |
700mm |
900mm |
1100mm |
|
Effictive width |
600mm |
800mm |
1000mm |
|
Take-up speed |
10-120m/min |
10-120m/min |
10-120m/min |
|
Take-up motor |
1.5kw |
2.2kw |
3.7kw |
|
Winding unit |
|
||
|
Winding type |
Friction type double winding |
Friction type double winding |
Friction type double winding |
|
Winding speed |
10-120m/min |
10-120m/min |
10-120m/min |
|
Voltage |
380V,50HZ,3PHASE |
380V,50HZ,3PHASE |
380V,50HZ,3PHASE |
|
Machine weight |
3T |
3.5T |
4T |
|
Machine size |
6*3*5.2m |
6*3.5*5.8m |
6*4*6.2m |
